1988 KELLENBERGER UR175x1000CNC CNC Universal Grinding Machine

KELLENBERGER CNC Universal Grinding Machine

Type:UR175x1000CNC

Year:1988

Control:KELCO 70

Distance between centres:1000mm

Max. grinding height:175mm

Max. workpiece diameter:349mm

Grinding wheel size:400x63x127mm

Grinding spindle speed:2040rpm

Table travel:1100mm

Cross slide travel:270+100mm

Workhead swivel:360°

Machine weight:3900kg

Please Note: The above information has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. Specific tooling must be requested before purchasing, since machines are in production at time of photos and availability can not be guaranteed. We advise you to check any vital details!
