2005 LEADWELL V-30 Vertical Machining Centre

2005 LEADWELL V-30 Vertical Machining Centre

Categories: ,

LEADWELL Vertical Machining Centre

Type:V-30

Year:2005

Control:FANUC 0i-MC

XYZ travel:760x410x410mm

Toolchanger:20atc

Spindle speed:8000rpm

Table size:890x400mm

Table height:780mm

Max. table load:300kg

Spindle taper:BT40

Distance from table top to spindle end:130-540mm

Distance from column front to spindle centre: 438mm

Machine size-LWH:2250x2100x2368mm

Machine weight:4500kg

With manuals

With swarf conveyor
