2020 OKUMA LB3000 EXII CNC turning Centre with Y-axis, C-axis, sub spindle and live tooling

OKUMA CNC turning Centre with Y-axis, C-axis, sub spindle and live tooling

Type:LB3000 EXII

Year:2020

Control:OSP-P300LA Suite

Y-axis:+70mm / -50mm

W-axis:800mm

Distance between centres::1020mm

Turning diameter over bed:580mm

Turning diameter over cross slide:470mm

Max. workpiece diameter:410mm

Spindle bore:91mm

Main spindle speed:4200rpm

Sub-spindle speed:6000rpm

Toolchanger:12atc

Machine weight approx.:6850kg

With automatic doors (original from the factory)

With parts catcher

Option extended tool data management

Smoke extraction

Media files can be downloaded via the following link:

Please Note: The above information has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. Specific tooling must be requested before purchasing, since machines are in production at time of photos and availability can not be guaranteed. We advise you to check any vital details!
